Alpine EF Series

UTE EF-102 End Former

UTE’s EF Series pipe end formers are designed with a self-contained hydraulic system for fast production with precise, repeatable results. Constructed from a square tube frame for maximum strength and durability, these pipe end formers are designed with off-the-shelf parts making maintenance a breeze. The machine guard is completely enclosed with a tamper-proof interlock for worker safety and security. These end formers come standard with a 5.5” touchscreen with optional controllers available. This versatile line of pipe end formers can tackle any challenge and deliver quality results, every time.

Standard Features

5.5’’ Touchscreen
Square Tube Frame Construction
NEMA 12 Enclosures
Completely Enclosed Machine Guard w/Tamper Proof Interlock
Foot Activation Switch
Quick Change Tooling Design
Self-Contained Hydraulic System
Jog Mode
Auto Shutdown After 2 Minutes
Self Diagnostics
Cycle Counter
One Year Limited US Warranty

Optional Features

Allen Bradley Controller
G.E. Fanuc Controller
Omron Controller
Modicon Controller
Parts Lubricator
Auto Loader/Unloader

OD Capacity Specifications

UTE-EF-101 1 hit Up to 1″ OD
UTE-EF-102 2 hits Up to 1″ OD
UTE-EF-104 4 hits Up to 1″ OD
UTE-EF-202 2 hits Up to 2″ OD

Starting at $249,900*

Available in multiple sizes / capacities with additional equipment upgrades

*Base price without upgrades
